Products

Time taken: 3 Max score: 1000.000 Total hits: 100 Full time: 0.0 s
Showing 1-10 of 100 products

B07MH6Q39N Price: $30.09 Score: 1000.000 Category: Electronics Rating: 4.5 Votes: 112 Find similar products Mcbazel Surecom 0014-0155 PL259 Male Plug DC to 1.0GHz 60W Watt 50 Ohm Dummy Load. Description: PL259 Male Plug DC to 1GHz 60 Watt Dummy Load 50 Ohm Dummy Load Max input power: 60 Watt Frequency Range: DC to 1GHz Connector: PL259 Impedance: 50ohm Size: 45 x 72 mm (NOT include plug) Warning: When the input power is higher than the dummy provides , it will cause the damage of the product Why use the dummy load? A Dummy Load is a device used to simulate an electrical load during testing. In an RF System a dummy load is used to simulate an antenna. By using a dummy load instead of an actual antenna, the transceiver can be tested and configured without radiating radio waves. The Dummy Load is selected in a way so that it has a similar impedance to the real device that will be connected to the RF System.Not using a dummy load and leaving the port open, can result in some unwanted reflections which can damage the RF System. Also, using a real antenna in the testing phase can result in some unwanted transmission in the lab which will interfere with other devices and technologies being tested. Packing Includes: 1 x 60W DC-1GHz 50ohm Dummy Load.	B085X779NB Availability: Currently unavailable Score: 8.475 Category: Electronics Rating: 4.5 Votes: 26 Find similar products MWRF Source N Male RF Dummy Load, 50 Ohm (25W DC - 3GHz). Package: 1 PC 25W N Male RF Load Impedance: 50 Ohm Frequency Range:DC – 3GHz VSWR:≤ 1.2.
B07BDDM8RD Price: $6.99 Score: 7.143 Category: Electronics Rating: 2.5 Votes: 2 Find similar products NOYITO Voltage to Current Module 0-24V to 0-20mA. Features: Using single-chip embedded technology. Implement the industry standard voltage (0-24V) into an industry standard current (0-20mA). Linear output, output signal can be directly connected to the AD converter. Can be connected with a microcontroller with AD function. Easy to operate, can be fine-tuned by potentiometer. Module operating voltage: DC12-24V Pin Description: 24V: Operating power supply 24V DC +. GND: 24V DC-. P1: Adjustable potentiometer 1 pin; VIN + (V + / P2): Input voltage ,0-24V DC- (OR adjustable potentiometer 2 pin). VIN- (V- / P3): INPUT DC- (OR adjustable potentiometer 3 pin) 0V: Output current 0-20mA Special Instructions: The working voltage connected to V + and V-, can not be reversed, so as not to damage the control panel and components. In the VIN terminal control voltage, the range is 0-5V, there is a corresponding output at the output current. The correspondence between voltage and current can be fine-tuned by adjusting the potentiometer. Package Included: 1 Pcs NOYITO Voltage To Current Module NOYITO brand products have a two-year after-sales warranty. If there is a non-human product failure within two years, please contact us. We will provide you with after-sales service.	B07ZFNCJ5N Price: $12.79 Score: 6.993 Category: Electronics Rating: 4.6 Votes: 23 Find similar products 4.3/10 Mini DIN connector Male Plug to N Female Jack Adapter 4.3-10 Mini DIN male to N female Aadptor. 4.3-10 Mini DIN male to N female Aadptor 1.Electrical Characteristic Impedance : 50 ohm Frequency Range :DC-6GHz VSWR ≤1.10 Insertion loss≤0.1dB PIM3 ≤-160dBc Dielectric Withstanding Voltage ≥2500V RMS,50Hz,at sea level Dielectric Resistance ≥5000MΩ Contact Resistance : Outer contact≤1mΩ;Center Contact≤1.0mΩ 2.Material and plating Body Brass Tri-Alloy plated Insulator PTFE (teflon) Center conductor Phosphor bronze Ag plated Temperature Range -40℃～+85℃.
B07FMQKF9K Price: $8.5 Score: 6.849 Category: Electronics Rating: 4.4 Votes: 52 Find similar products NOYITO AC to DC Precision Buck Power Supply Module AC 120V 100V-264V to 5V 1.5A 1500mA Isolated Step Down DC Module (5V 1.5A). Description Isolated Precision Buck Power Supply Module ，Wide voltage range input with overload, short circuit, over temperature protection. Ultra-small size and high efficiency. Output parameters: Output voltage: 5V ±1%. Output current: 1.5A 1500mA. Ripple: less than 60mVp-p. Output accuracy: ±1%. Voltage regulation rate: ±1%. Load adjustment rate: ±1.2% Rated power: 7.5W. Output adjustable range: not adjustable. Establish, rise, hold time: 500ms, 80ms, 80ms / 220V AC. Input parameters: Input voltage range: AC 100- 264V. Input current: less than 0.2A. (Average current 0.03A-0.1A). Frequency range: 47-63Hz. Efficiency: about 80%. Start surge current: COLD START 30A/230V / AC. Leakage current: less than 2mA / 220V AC. Protection features: Over power protection: 150-170% rated power. (Fault removal is automatically restored). Overvoltage protection: VH: >50%. DC short circuit protection: The power supply is intermittently separated. (Recovery is automatically restored). Environmental parameters: Working temperature: -15 ° C - +50 ° C @ 100% LOAD , +60 ° C @ 60% LOAD; Working humidity: 20%-90% RH. Storage temperature, humidity: -20 ° C - +85 ° C, 10% -95% RH. Safety and EMC standards: Withstand voltage: I/P-O/P: 1KV AC 1min. Insulation resistance: I/P-O/P: 500VDC / 100M Ohms. Package Included: 1Pcs 5V 1.5A 1500mA AC-DC Precision Buck Power Supply Module.	B00C2JI4P0 Availability: Currently unavailable Score: 6.757 Category: Electronics Rating: 3.1 Votes: 8 Find similar products DROK AC to DC Buck Converter Voltage Regulator Step Down AC 15-26V to DC 15-40V 24V to 12V DC Voltage Adjust Module for CCD/CCTV Regulated Power Supply. Feature: Input Voltage: AC 17-26V or DC 17-40V ( Input regardless of positive and negative ) Output Voltage: 12VDC Output Current: 2A Max Total Power: 24 Watt Output interface: outer Diameter 5. 5mm, inner core 2. 1mm Output polarity: inside positive, Outside the negative Output ripple (Output Noise): = 80% Environment Operation temperature: -20°c to 60°c The average working life (MTBF)：>20000Hour Dimensions: 58mm x 40mm x 22mm Protection function: Output short circuit protection Output overcurrent protection Output overload protection Some Application: CCD Camera, CCTV System, Gateway or other 12VDC Power Supply device etc. Package Including: 1x DC Converter.
B07G446KHJ Price: $5.99 Score: 6.757 Category: Electronics Rating: 3.6 Votes: 12 Find similar products NOYITO DC to DC 5A Adjustable Buck Regulator Power Supply Module CC CV DC 5V - 32V Buck to 0.8V - 30V Output ADJ Constant Voltage Constant Current Step-Down Power Supply Module LED Driver Board. Features: The module uses high-quality chips, high efficiency (up to 95%), low heat generation, maximum 5A current, and TI's op amp control output current, making the overall output very stable. This module uses a low-ESR filter capacitor to reduce ripple voltage to 50mV! Module nature: non-isolated buck module Rectification mode: asynchronous rectification Wiring port: Input mode: IN+ input positive, IN- input negative Output mode: OUT+ output positive, OUT-output negative Input voltage: DC 5V-32V Output voltage: DC 0.8V-30V Output current: Adjustable , Max 5A Conversion efficiency: 95% (maximum) Switching frequency: 300KHz Output ripple: 50mV (maximum) 20M bandwidth Load adjustment rate: +/-0.5% Voltage regulation rate: +/- 2.5% Operating temperature: -40°C to +85°C Size: 5126.314 (length * width * height) (mm) Package Included: 1Pcs NOYITO DC-DC 5A Adjustable Buck Regulator Power Supply Module.	B085VYBJ3N Price: $16.1 Score: 6.667 Category: Electronics Rating: 2.6 Votes: 3 Find similar products Multifunctional PWM Signal Voltage Current Converter Module PWM Signal to 0-20MA 0-3.3V/0-5V/0-10V Voltage to 0-20MA. Specification: Item Type: Conversion Module Supply Voltage: DC8-30V, (recommended supply voltage is 24V, high voltage supply can support wider signal load internal resistance) Maximum Supply Current Consumption: 35mA/24V The PWM Input Interface Supports Signal Level Types: TTL signal level, NPN-OC signal input. 24VVPP signal level input, PNP type PWM signal input is not supported by default. The PWM Signal Supports The Frequency Range: 50HZ~4KHZ. It is recommended to use between 1-2KHZ. The current accuracy of the module output: ±3%, temperature drift value: less than 3%. Maximum Support Output Internal Resistance: 200Ω. Size: Approx. 4.8 x 4.4 x 2cm / 1.9 x 1.7 x 0.8in, 4xM3 screw fixing holes Package List: 1 x Conversion Module Feature: 1. Digital PWM signal input controls analog 0-20MA current output 2. Support 0-3.3V/0-5V/0-10V voltage analog signal input control 0-20MA current output 3. The adjustable potentiometer on the board is used to match the different signal sources to correct the contrast relationship 4. The 5V-OUT interface supports 50MA current externally and can be used by external circuits 5. The module current output interface is directly shorted to the ground wire and will not be damaged.
B07GMHLL2M Price: $6.99 Score: 6.623 Category: Electronics Rating: 4 Votes: 58 Find similar products NOYITO PC817 4-Channel Optocoupler Isolation Board Voltage Converter Adapter Module 3.6-30V Driver Photoelectric Isolated Module. Parameter Drive terminal signal voltage: 3.6-24V. Output terminal voltage range: 3.6-30V (output current depends on the specific situation but the maximum does not exceed 10MA, the total power is constant, the voltage and current are inversely proportional) Whether the output is a high potential output or a low potential can be realized by a jumper cap. The 4 channels 817 are separated., can achieve simultaneous control of different voltages, etc. Board size: 48mm x 38mm (length and width); long side hole distance: 42mm; wide side hole distance: 32mm Package Inluded: 1pcs NOYITO PC817 4-Channel Optocoupler Isolation Board.	B003EE05Z4 Availability: Currently unavailable Score: 6.623 Category: Electronics Rating: 5 Votes: 1 Find similar products AIR802 N-Jack Female to N-Female Bullet Adapter. AIR802 manufactures high precision and performance adapters and connectors. Adapter and connector selection is extremely important to insure proper operation and reliability. Poorly constructed adapters and/or connectors will cause higher VSWR and insertion loss resulting in electrical noise and intermittent issues. AIR802 manufactures very large quantities of adapters and connectors for our global customers allowing us to provide an attractive quality to price ratio. In choosing adapters and/or connectors, it is important to match one to the type of cable being used, the impedance (50 versus 75 ohms), the frequency support, insertion loss, voltage rating and environmental specifications. Adapters are very useful for matching different connector types. This is a N-female to N-female bullet adapter. N type connectors were developed in the 1940's by Paul Neill of Bell Labs and were one of the first connectors capable of transmitting microwave frequencies. N type adapters and connectors are manufactured in both 50 and 75 ohm versions. Our N type adapters and connectors are all 50 ohm varieties. Specifications Impedance: 50 ohms Frequency Range: DC ~ 11 GHz Voltage Rating: 1500 Volts Peak Dielectric Withstanding Voltage: 2500 Volts RMS Insertion Loss: .15 dB Max. Body: Nickel Plated Brass Contact: Gold Plated Brass Insulator: TFE Mating: 5/8-24 UNEF Threaded Mating Torque: 15 inch pounds Max. Temperature: -67°F to 185°F (-55°C to 85° C) RoHS Compliant: Yes Corrosion: MIL-Std. 202 Method 101 (Test Condition C) Temperature Cycling: MIL-Std. 202 Method 102 (Test Condition C) Altitude: MIL-Std. 202 Method 105 (Test Condition C) Vibration: MIL-Std. 202 Method 204 (Test Condition B) Moisture Resistance: MIL-Std. 202 Method 106 (Test Condition B).
